APT-3100
- 첨부파일0
- 추천수
- 0
- 조회수
- 842
내용
▶ CATALOG ▶ MANUAL    (same as APT3100)▶ The ATT-3100 Smart Pressure Transmitter is a micro processor-based high performance transmitter, which has flexible pressure calibration and output, automatic compensation of ambient temperature and process variable, configuration of various parameters, communication with HART protocol.
    The application is very various, as measuring Pressure, Flow and Level by application method.
    All Data of Sensor (Tag No., type, range etc.) is to be input, modified and stored.
    HART communication can be Max 1.5Km.
    In Multi-drop Mode, Max 15 Transmitters can be connected and communicated with Host.
| Features |
|---|
| - Superior Performance   • High Accuracy : ±0.075% of Span (at 20℃)   • Long-Term Stability - Flexibility   • Selection of various Pressure : DP,GP   • Data confirguration with HART configurator   • High Reangeability (100:1) - Reliability   • Continuous Self Diagnostic Function (sensor, memory, Communication).   • Automatic Compensation : Linearization of sensor input, Ambient temperature - Compensation   • Fail-mode process function by hardware and software   • EEPROM Write Protection   • CE EMC Conformity Standards(EN50081-2,EN50082-2) |
| Specifications | |
|---|---|
| Flexible Sensor input | Absolure Pressure, Vacuum |
| Various output | 4 ~20mA(Analog), Digital Signals |
| Setting Various Parameters | Zero/Span, Fail-mode, Unit, Trim, etc. |
| Setting Various Parameters | Sensor, A/D Converter, Memory, Power, etc |
| Digital Communication | HART protocol, Command |
| Flame-Proof Approval | (KOSHA Ex d IIC T6) – (option), (KTL Ex ia II C) – (option) |
| Working Pressure Limits (silicone oil) | 0 to 400 kPa for Range 4 0 to 1500 kPa for Range 5 0 to 3000 kPa for Range 6 |
| Hydrostatic Test Pressure | Range 4 : 58 psi ( 400 kPa) Range 5 : 218 psi ( 1500 kPa) Range 6 : 435 psi ( 3000 kPa) |
| Burst Pressure | 2000 psig (13.8 MPa) |
| Automatic Compensation of Ambient Temperature | |
