Flow

VEGAPULS 61
▶ CATALOG (same as VEGAPULS Series) ▶ You can get a MANUAL
in Download tab▶ VEGAPULS 61 is suitable for applications in liquids in smaller vessels under easy process conditions.
The application possibilities can be found in virtually all industries.
Extremely short microwave pulses are emitted via the antenna system to the measured product, reflected by the product surface and received again by the antenna system.
The time from emission to reception of the signals is proportional to the level.
A special evaluation procedure ensures a reliable and precise measurement.
Features- Non-contact measurement
- Simple mounting
- Unaffected by pressure, temperature, gas and dust
- High measuring accuracy
Specifications Process fittingG1½A, mounting loop or FlangeMeasuring rangeup to 20 mAccuracy+/- 2 mmProcess temperature-40 … +80 °CProcess pressure-1 … +2 bar
(-100 … +200 kPa)Emitting frequencyK-Band Flovel

댓글수0
VEGAPULS 62
▶ CATALOG &nbsp (same as VEGAPULS Series) ▶ You can get a MANUAL
&nbsp &nbsp in Download tab▶ VEGAPULS 62 is suitable for applications in liquids in storage tanks or process vessels under arduous process conditions.
&nbsp &nbsp Application possiblities are in the chemical industry, environment and recycling as well as in the petrochemical industry.
&nbsp &nbsp Extremely short microwave pulses are emitted via the antenna system to the measured product, reflected by the product surface and received again by the antenna system.
&nbsp &nbsp The time from emission to reception of the signals is proportional to the level.
&nbsp &nbsp A special evaluation procedure ensures a reliable and precise measurement.

Features - Non-contact measurement
- Simple mounting
- Unaffected by pressure, temperature, gas and dust
- High measuring accuracy
Specifications Process fittingTread or FlangeMeasuring rangeup to 35 mAccuracy+/- 2 mmProcess temperature-200 … +450 °CProcess pressure-1 … +160 bar
(-100 … +16000 kPa)Emitting frequencyK-Band Flovel

댓글수0
VEGAPULS 63
▶ CATALOG &nbsp&nbsp (same as VEGAPULS Series) ▶ You can get a MANUAL
&nbsp &nbsp in Download tab▶ VEGAPULS 63 is suitable for measurement of very aggressive liquids or under special hygienic process conditions.
&nbsp &nbsp Application possiblities are in the chemical as well as in the food processing and pharmaceutical industry.
&nbsp &nbsp Extremely short microwave pulses are emitted via the antenna system to the measured product, reflected by the product surface and received again by the antenna system.
&nbsp &nbsp The time from emission to reception of the signals is proportional to the level.
&nbsp &nbsp A special evaluation procedure ensures a reliable and precise measurement.

Features - Non-contact measurement
- Front-flush installation
- Simple mounting
- High measuring accuracy
- Unaffected by pressure, temperature, gas and dust
Specifications Process fittingFlange or Hygienic fittingMeasuring rangeup to 20 mAccuracy+/- 2 mmProcess temperature-170 … +200 °CProcess pressure-1 … +16 bar
(-100 … +1600 kPa)Emitting frequencyK-Band Flovel

댓글수0
